Valve & Pump Packings

PK3800 is a high performance hatch packing designed for road, rail and sea hatches. With an EPDM Rubber core and PTFE wrapped outer cover it has excellent recovery characteristics after repeated compression and is impervious to liquids and chemicals.

The product is available in square or rectangular cross sections to accommodate any irregularities in the tank lid and can be supplied in continuous coil, cut lengths or pre-formed endless rings to suit your needs.

The product is accepted by US Coastguards for use with Propylene Oxide and 1,2 -Butylene Oxide.

A Natural Fibre Based Packing designed specifically for Fresh & Sea Water Applications.

A Natural Fibre based Packing designed for Fresh & Sea Water Applications

A high performance Packing manufactured from an expanded PTFE Yarn (ePTFE) using the Crossplait Technique suitable for any application where contamination cannot be tolerated. Designed for Food & Drink Industry but also used in Pharmaceutical, Medical, Fine Chemicals & Paper Industries.

A high performance PTFE Packing with no impregnation or additives, designed for use on Oxygen Applications and suitable for use with All Chemicals.

A high performance packing manufactured from a specially lubricated PTFE Yarn, suitable for all chemicals and solvents.

A superior performance Packing manufactured from Graphited ePTFE yarn using the Crossplait Technique. Designed to operate on High Speed, Rotary & Reciprocating Applications.

A high performance multi-filament Graphited PTFE Packing impregnated with High Temperature Lubricant. Recommended for its excellent performance at high pressure and its anti-extrusion properties.

Manufactured from Pure Expanded Graphite containing minimum amounts of trace elements such as Sulphur & Chloride then reinforced with Inconel Wire.

Manufactured from Pure Expanded Graphite containing minimum amounts of trace elements such as Sulphur & Chloride.

A superior quality low emission Packing, manufactured to ISO15848-1:2006and tested to Shell SPE77/312, constructed from exfoliated graphite reinforced by knitted inconel wire mesh, designed to reduce fugitive emissions with ease and requires no special fitting technique.

Manufactured from the highest quality pure graphite filament yarn impregnated with PTFE. This is an excellent packing for rotating & reciprocating pumps & valves.

A packing manufactured from High Strength Aramid Yarn, each filament coated with PTFE. Excellent operating length over a wide range of applications.

A superior performance graphited PTFE yarn in the core and seams with a high strength aramid yarn for the corners. This is designed for minimal shaft wear in when used with abrasive media.

A cost effective universal packing manufactured from Aramid and pre-oxidised acrylic. This packing has excellent chemical resistance, low surface friction and low permeability.

Manufactured from BCX yarn manufactured with a Graphite Lubricant, this packing is specifically designed for use on hot air and gases and has a low co-efficient of friction.

A high temperature valve packing for slow rotating and static applications specifically designed for hot air and gases. Ideal for sealing high temperature ducting and exhaust manifolds.

P090 is manufactured from pure PTFE spirally wrapped to form a cord for fitting into restricted gland spaces. This production method reduces lateral flow and the possibility of extrusion. For use in Valve Gland Packings or universal flange gasket. Suitable for use with water, steam, oils, solvents, oxygen, gases and all chemicals with the exception of molten alkali metals and fluorine.
